Al/XLPE/FR PVC Aluminum power cable

Application

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed

Apply to shafts, water and soil, able to bear the larger positive pressure.

International: IEC 60502, IEC 60228.IEC 60332.1

China: GB/T 12706, GB/T 19666-2019

Other standards such as BS, DIN and ICEA upon request.

Technical data

Rated voltage: 0.6 / 1 kV

Maximum Conductor Temperature: under normal (90℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions. Min. Ambient Temp.   -15℃, Installation Temp. 0℃

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position.

Min. Bending Radius: 20 x cable O.D for single core

15 x cable O.D for multi core.
